Masterclock, Inc.



phone(USAandCanada):1‐800‐940‐2248|phone(international):+1‐636‐724‐3666

email:[email protected]|online:www.masterclock.com



CombinespowerneedsforanorderlyinstallationofMasterclockequipment.

MountsinRM4rack‐mounttosupply28VpowerforuptonineMasterclockrack‐mounteddevices.



FEATURES

Universalrackmountedpowersupply

• Outputs28VDC

• Inputs90‐240VAC/47‐63Hzor90‐240DC

• 45‐wattcapacity

• IECinputconnector

• ThreeeachDCpowerplugs(powercapacitysupports

uptonineMasterclockdevices)



SPECIFICATIONS

Outputs

• ThreeDCjacks,28VDC



Connectors

• IECpowercord

• Powerplugs:Threeeach2.1mmDCmalepowerjacks,

SwitchcraftL722A



OperatingParameters 

• Temperature:0to+70°C

• Humidity:Upto90%,non‐condensing





Physical

Size:

4.13wx1.5hx5.5dinches

Weight:

16oz

10.48wx3.81hx14dcm 435g

   

Case

• Cover:Off‐whitealuminum

• Front/rearpanel:Clearanodizedaluminum

• Optionalrackmountkitavailable─RM4



Universal Power Suppl

PSU 45

Rack mountable with an RM4
