Masterclock, Inc.



phone(USAandCanada):1‐800‐940‐2248|phone(international):+1‐636‐724‐3666

email:[email protected]|online:www.masterclock.com



ReferenceOptions

• GPS(atomicclock)

• NTP

• TimeCode

• HighStabilityOscillator

• NMEA0183

• NENA911PSAPStandard 



OutputOptions

• NTP

• TimeCode

• Truetime/Kinemetrics

• NMEA0183

• NENA911PSAPStandard

• PPO

• PPS

• 10MHzsinewave



MODULARFEATURES

ReferenceSources

• GPSantenna/satellites

• NTPviaEthernet

• VariousTimeCodes:IRIGA,BandE,SMPTE,EBU

• Internalhigh‐stabilityOCXOoscillator±0.25min/year

• NMEA0183viaRS‐232orUSB

• NENAFormat0,1and8viaRS‐232orUSB



Outputs

• PCtimesetviaUSBserial

• NTPclientvia10/100MbEthernet

• VariousTimeCodes:IRIGA,B,andE,SMPTE,EBU

• NMEA0183viaRS‐232orUSB

• NENAFormat0,1and8viaRS‐232orUSB

• 5Vat20mAPulsePerSecondand

ProgrammablePulseOutput

• 10MHzsinewave

• DB9breakoutadapter

TheMCR1000MasterClockReferencesystemisacompact,precision

timeandfrequencydevice.OneunitcanreferenceandoutputNTP,Time

Codeanda10MHzsinewavealllockedtotheatomicclocksinGPS

satellites.Ahigh‐stabilitycrystaloscillator(OCXO)actsasaninternal

sourceofaccurate

timeincaseGPSsignaliseverlost.

Withspecsequalorbetterthanalmostanyothersimilarproduct,the

MCR1000isupto60%lessexpe nsive thanitscompetitionandavailable

inmultipleconfigurationstofitalmostanyneed.

Multi-Functional Master Cloc

MCR 1000

RackmountablewithanRM4

OtherFeatures

• Programmablerelayclosure.

1eventperdaywithNO/NCdrycontactrelay,

24V‐AC/DC(250mAmax)

• 6‐or9‐digitdisplay

• Optionalrelayschedulerformultipleevents



Physical

Size:



6.75x4.13x1.5in Weight:



17.3oz

17.15x10.48x3.81cm 490.5g

Power

DCinput‐Threadedlockingplugwithexternalpoweradapter



EnvironmentalParameters

• Temperature:0to+60°C(0to40°C±1min/year)

• Humidity:Upto90%,non‐condensing
