Masterclock TCR1000 Specifications download pdf (Page 47)

Masterclock, Inc.



phone(USAandCanada):1‐800‐940‐2248|phone(international):+1‐636‐724‐3666

email:[email protected]|online:www.masterclock.com

May2012Masterclock



 

FEATURES

• 1”(2.54cm),6digitLED–displaycolorsavailableinamber,blue,redandgreen

• AutomaticallydetectsandsyncstoIRIG‐BorSMPTE,EBUnon‐dropframetimecodes

• Six‐digittimedisplayin12‐or24‐hourformatordate

• Allinternationaltimezonesandautomaticdaylightsavingtimes

• Standardchassiscolorisblackpowdercoat;othercolorsavailable

• UniversalworldwideACpower

• Countdownorcountupcapable(usingRC500)

• CEmarkedforsaleinEU–FCC,classB,emissions(pending)



SPECIFICATIONS

SetupandControlSoftware

• ConfigureclocksthroughUSBserialinterface

• Configurationutilityrunnin gunderMicrosoft

WindowsOperatingSystemsXPorbetter

• World‐widetimezoneandDSTsupport–

noconfigurationswitches

• Up/downtimermode–controlledwithRC500

viaRS‐485port

• Configurationissavedtonon‐volatilememory

andsurvivespowerlosses



StandardRackMount–1RU–“Ears”removable

Size:

16.9wx1.7hx4.5din

Weight:

1.0lb

43wx4.31hx11.5dcm 0.45kg

FICATIONS

OperatingLimitations

• Temperature:0to+60°C

• Humidity:Upto90%(non‐condensing)



Connectors

• BNCfemale–UnbalancedTCinput

• Terminalblock–3position,balancedTCinput

• USBconnectorforsetup

• SmallIECconnector(320‐6)



Power

• Powerconsumption<15W

• International115/230,50/60Hz

• SuppliedwithchoiceofUS,Euro,Britishor

AUS/NZpowercord–othersavailable

SWIVEL BRACKET

OPTIONAVAILABLE

Rack Mount Time Code Cloc

TCDS16
